Product Details

These heavy duty gussets are designed to take serious abuse and reinforce your front 30 or Rubicon 44 Inner C's. The 1/4 inch thick precision cut and formed components of this setup out perform the competition.

Details:

• Sold as Each


• Install Note:It It Recommended To remove The Upper Ball Joint Prior To Welding These Inner C Gussets.


• Features include:


• 1/4 inch mild steel.


• Precision CNC cut and bent For great fitment.


• Laser etched part numbers For easy installation


• Designed using CAD files directly from Chrysler For a precision fit Inch tight area around inner C.


• Provides valuable reinforcement to an area prone to abuse and flex.


• Clearanced For stock and aftermarket coil springs


• Boxed structure offers more rigidity over single plate Style gusset


• Gussets both top and bottom of Inner C For a complete solution.


• Some grinding and fitment may be required when installing this Kit.


• Every axle varies slightly and some fabrication may be required.


• Clearancing on the top gussets around the coil spring may be necessary depending on coil spring thickness.


• This Kit requires general welding and fabrication skills.


• Welding should only be done by a competent welder.


• Artec Industries implies no guarantees or warranties and is not liable For improper installation.
